NCC MEDICAL professional electroencephalogram EEG machine

Amplifier

Inputchannels: 9/20/40 channels(8/19/39 channel EEG and 1 channel Bipolar ECG)

Powersupply: 4AA batteries,or external rechargeable lithium battery;

ContinuousMonitoring Time:up to 72 hours with 4 AAbatteries;

Internalmemory:Built-in Flash memory card (2GB);

Connection toPC: WirelessBluetooth for real-time data transmission; USB (2.0) for data uploading fromFlash memory card.

OperationModes:Real-time; LTM(Long Term Monitoring)

SamplingRate: 128Hz, 256Hz,512Hz

Input impedance:≥10MOhm

A/Dconversion: 16bit

CMRR:≥100dB;

Noise:≤0.5uVRMS;

Low-pass filter:1~60Hzarbitrary;

Amplitude-frequencycharacteristic: 0.5~60Hz;

High-passfilter:0.01s, 0.02s,0.03s, 0.1s, 0.2s, 0.3s, 1s, 2s, 3s (16Hz, 8Hz, 5.3Hz, 1.6Hz, 0.8Hz, 0.5Hz,0.16Hz, 0.08Hz, 0.05Hz);

Interface: USB2.0,interface transfer rate: 480Mb/s;

Dimension &Weight: 130*89*40mm;250g (Amplifier only).


Key Features &Advantages

1. Amplifier functions: Integrates allthe functions of signal magnification, A/D transform, data storage, LCD displayand wireless data transmission, capable of showing one channel waveform(arbitrarily and can be changed), present time, collection time, storagecapacity, version information, serial number and batterystatus;

2. Input channels: Supports 19 EEG channels plus 1 channel ECG to meet with doctor's clinical requirements in international 10/20 placement;

3. Long time monitoring: Low powerconsumption, capable of supporting up to 72 hours recording with 4 AAbatteries;

4. Safety & low interference: Use ofDC power supply eliminates risk of electric shock to patients and preventssignal interference, and removes the need for ground wire or other shieldingfeatures;

5. Recording mode: Supports real-timeEEG waveform recording and display via Wireless Bluetooth transmission, ordynamic recording with flash memory card capable of storing up to 2GB of EEGdata (data storage capability depends fully on memory cardused);

6. Powerful playback function: amplitudeand playback rate can be adjusted freely to meet doctor'sneeds.

7. Report modes: EEG software providesvarious reports to meet doctors' need.

8. Data conversion: The case dataacquired can be converted to EDF or TXT format, which is convenient for furtheranalysis and academic exchange.

9. Event marking ability: Event buttonon the amplifier enables on-the-spot manual event marking of patient's epilepsyseizure during recording;

10. High quality electrodes:Single-shielded electrodes with touch proof connectors that meetsinternational standard, and can be replaced individually ifnecessary;

11. Convenient application: Compactdesign and easy to carry, complete with EEG signal isolation to support maximumpatient movement without distortion;

12. Optional parts: Optional videosystem for recording, editing and displaying video images synchronously with EEGsignals.
